The Precision Raceworks E9x / E8x LOW PRESSURE BUCKETED FUEL PUMPS are designed for customers looking to run all blends of E85. All pump options below include Genuine Walbro 450 (F90000274), Walbro 525 (F90000285), or Walbro 535 (F90000295) fuel pump(s) capable of flowing up to 350% more fuel than the factory fuel pump and all options are 100% E85 compliant.
-
Stage 2 (2.4 gallons per minute)
Our Stage 2 bucketed fuel pump comes with a single Walbro 450 (F90000274) fuel pump. This pump can support up to 575whp (Rated for 500whp on 100% E85) and is ready to grow with you as your needs demand. Unlike other manufactures we are the only company featuring a bucketed kit with a modular design. This means you can purchase our stage 3 pump module or Stage 3.5 module and upgrade our pumps as your needs change.
-
Stage 2.5 v2 (3.1 gallons per minute)
Our Stage 2 bucketed fuel pump comes with a single Walbro 535 (F90000295) fuel pump. This pump can support up to 650whp (Rated for 550whp on 100% E85) and is ready to grow with you as your needs demand. Unlike other manufactures we are the only company featuring a bucketed kit with a modular design. This means you can purchase our stage 3 pump module or Stage 3.5 module and upgrade our pumps as your needs change.
ASSEMBLY OPTIONS
All kits are fully assembled and ready to drop-in!
While all bucketless fuel pumps flow .2gpm more than a bucket design that retains the venturi it comes at a cost. Bucketless pumps should not be driven on tanks lower than ¼ full and should not be used for road course racing. This is not a disadvantage of only bucketless designs but also a disadvantage for any bucket design which deletes the venturi. If you do not plan on road course racing (not street racing) and are responsible at maintaining ¼ tank of fuel during spirited driving bucketless pumps can be a cheaper alternative for you.
*To reach the advertised ability of these fuel pumps use of the Precision Raceworks in tank filter regulator assembly is required.
** Some European Spec vehicles may require re-use of top hat due to differences in emissions requirements.
This is a true plug and play solution that anyone can install in their home garage and start taking advantage of the benefits right away.
For more details see the specifications tab
Specifications
Lock Ring Tool Included: NO - Available Here
-
Factory BMW pump
- Pump flow 72psi (5bar): XXX GPM
- Pump Weight:
- Horsepower Supported Pump Gas:
- Horsepower Supported 100% E85: NOT COMPATIBLE
-
Stage 2
- Pump flow 72psi (5bar): XXX GPM
- Pump Weight:
- Horsepower Supported Pump Gas: 575
- Horsepower Supported 100% E85: 500
- Aftermarket EKP Required: No
-
Stage 2.5 v2
- Pump flow 72psi (5bar): XXX GPM
- Pump Weight:
- Horsepower Supported Pump Gas: 650
- Horsepower Supported 100% E85: 550
- Aftermarket EKP Required: No
